Select model

F12.06F12.05F12.04F12.03F12.02F12.01
Rear Derailleur
SHIMANO 105 7100 12v
Front Derailleur
SHIMANO 105 7100
Shift Lever
SHIMANO 105 7120
Cranks
SHIMANO 105 7100 34x 50
Cassette
SHIMANO 105 R7100 11x 34
Brakes
SHIMANO 105 7170
Brake Rotor
SHIMANO RT70 140 mm
Wheel
MAVIC KSYRIUM 30
Cockpit
VISION METRON 5D ACR INTEGRATED 3K
Handlebar
VISION METRON 5D ACR INTEGRATED 3K
Seatpost
F12 MONOCASCO CARBON
Saddle
SELLE SAN MARCO SHORTSIFT DYNAMIC
Rear Derailleur
SHIMANO 105 Di2 7150
Front Derailleur
SHIMANO 105 Di2 7150
Shift Lever
SHIMANO 105 Di2 7170
Cranks
SHIMANO 105 7100 34x 50
Cassette
SHIMANO 105 R7100 11x 34
Brakes
SHIMANO 105 7170
Brake Rotor
SHIMANO RT70 140 mm
Wheel
MAVIC KSYRIUM 30
Cockpit
VISION METRON 5D ACR INTEGRATED 3K
Handlebar
VISION METRON 5D ACR INTEGRATED 3K
Seatpost
F12 MONOCASCO CARBON
Saddle
SELLE SAN MARCO SHORTSIFT DYNAMIC
Rear Derailleur
RIVAL AXS D1
Front Derailleur
RIVAL AXS D1
Shift Lever
RIVAL AXS D1
Cranks
RIVAL D1 35/48
Cassette
XG-1250 D1 10/30
Brakes
RIVAL D1
Brake Rotor
PACELINE 140mm
Wheel
MAVIC KSYRIUM 30
Cockpit
VISION METRON 5D ACR INTEGRATED 3K
Handlebar
VISION METRON 5D ACR INTEGRATED 3K
Seatpost
F12 MONOCASCO CARBON
Saddle
SELLE SAN MARCO SHORTSIFT DYNAMIC
Rear Derailleur
FORCE AXS D1
Front Derailleur
FORCE AXS D1
Shift Lever
FORCE AXS D1
Cranks
FORCE D1 35/48
Cassette
XG-1270 D1 10/33
Brakes
FORCE D1
Brake Rotor
CLX R 140mm
Wheel
MAVIC KSYRIUM 30
Cockpit
VISION METRON 5D ACR INTEGRATED 3K
Handlebar
VISION METRON 5D ACR INTEGRATED 3K
Seatpost
F12 MONOCASCO CARBON
Saddle
SELLE SAN MARCO SHORTSIFT DYNAMIC
Rear Derailleur
SHIMANO ULTEGRA Di2 R8150
Front Derailleur
SHIMANO ULTEGRA Di2 R8150
Shift Lever
SHIMANO ULTEGRA Di2 R8170
Cranks
SHIMANO ULTEGRA R8100 34x 50
Cassette
SHIMANO R8100 12v 11x 30
Brakes
SHIMANO ULTEGRA R8170
Brake Rotor
SHIMANO RT800 140 mm
Wheel
MAVIC KSYRIUM 30
Cockpit
VISION METRON 5D ACR INTEGRATED 3K
Handlebar
VISION METRON 5D ACR INTEGRATED 3K
Seatpost
VISION METRON 5D ACR INTEGRATED 3K
Saddle
SELLE SAN MARCO SHORTSIFT DYNAMIC
Rear Derailleur
SHIMANO DURA-ACE Di2 R9250
Front Derailleur
SHIMANO DURA-ACE Di2 R9250
Shift Lever
SHIMANO DURA-ACE Di2 R9270
Cranks
SHIMANO DURA-ACE R9200 34x 50
Cassette
SHIMANO R9200 12v 11x 30
Brakes
SHIMANO DURA-ACE R9270
Brake Rotor
SHIMANO RT900 140 mm
Wheel
MAVIC COSMIC SL
Cockpit
VISION METRON 5D ACR INTEGRATED 3K
Handlebar
VISION METRON 5D ACR INTEGRATED 3K
Seatpost
F12 MONOCASCO CARBON
Saddle
SELLE SAN MARCO SHORTSIFT DYNAMIC
Next

Choose size

4548515457
B. Seat Tube Length
450 mm.
L. Top Tube Length
515 mm.
T. Head Tube Length
120 mm.
P. Chainstay Length
405 mm.
C. Wheel Base
973 mm.
F. Bottom Bracket to front wheel center
578 mm.
X. Head Tube Angle
71,5°
Z. Seat Tube Angle
75°
S. Stack
519 mm.
R. Reach
376 mm.
B. Seat Tube Length
480 mm.
L. Top Tube Length
536 mm.
T. Head Tube Length
140 mm.
P. Chainstay Length
405 mm.
C. Wheel Base
976 mm.
F. Bottom Bracket to front wheel center
581 mm.
X. Head Tube Angle
72,5°
Z. Seat Tube Angle
74°
S. Stack
541 mm.
R. Reach
381 mm.
B. Seat Tube Length
510 mm.
L. Top Tube Length
548 mm.
T. Head Tube Length
160 mm.
P. Chainstay Length
405 mm.
C. Wheel Base
978 mm.
F. Bottom Bracket to front wheel center
583 mm.
X. Head Tube Angle
73°
Z. Seat Tube Angle
73,5°
S. Stack
562 mm.
R. Reach
382 mm.
B. Seat Tube Length
540 mm.
L. Top Tube Length
565 mm.
T. Head Tube Length
180 mm.
P. Chainstay Length
405 mm.
C. Wheel Base
988 mm.
F. Bottom Bracket to front wheel center
593 mm.
X. Head Tube Angle
73.5°
Z. Seat Tube Angle
73.3°
S. Stack
583 mm.
R. Reach
390 mm.
B. Seat Tube Length
570 mm.
L. Top Tube Length
587 mm.
T. Head Tube Length
210 mm.
P. Chainstay Length
405 mm.
C. Wheel Base
1006 mm.
F. Bottom Bracket to front wheel center
612 mm.
X. Head Tube Angle
73.5°
Z. Seat Tube Angle
73°
S. Stack
611 mm.
R. Reach
400 mm.
Next

Choose color

Personaliza tu F12 Only

Puedes personalizar los colores de tu F12 en nuestro personalizador.

Access the customizer
Next
