Road

Configurator F9

Find a dealer

Select model

F9ICR.06 F9ICR.05 F9ICR.04 F9ICR.03 F9ICR.02 F9ICR.01

Rear Derailleur: SHIMANO 105 7100 12v
Front Derailleur: SHIMANO 105 7100
Shift Lever: SHIMANO 105 7120
Cranks: SHIMANO 105 7100 34x 50
Cassette: SHIMANO 105 R7100 11x 34
Brakes: SHIMANO 105 7170
Brake Rotor: SHIMANO RT70 140 mm
Wheel: MAVIC AKSIUM
Cockpit: DEDA SUPERBOX
Handlebar: DEDA ZERO2
Seatpost: F9 CARBON
Saddle: SELLE ITALIA MODEL X

Rear Derailleur: SHIMANO 105 Di2 7150
Front Derailleur: SHIMANO 105 Di2 7150
Shift Lever: SHIMANO 105 Di2 7170
Cranks: SHIMANO 105 7100 34x 50
Cassette: SHIMANO 105 R7100 11x 34
Brakes: SHIMANO 105 7170
Brake Rotor: SHIMANO RT70 140 mm
Wheel: DT SWISS P-1800 DB 32
Cockpit: DEDA VINCI
Handlebar: DEDA ZERO2
Seatpost: F9 CARBON
Saddle: SELLE ITALIA MODEL X

Rear Derailleur: RIVAL AXS D1
Front Derailleur: RIVAL AXS D1
Shift Lever: RIVAL AXS D1
Cranks: RIVAL D1 35/48
Cassette: XG-1250 D1 10/30
Brakes: RIVAL D1
Brake Rotor: PACELINE 140mm
Wheel: DT SWISS P-1800 DB 32
Cockpit: DEDA VINCI
Handlebar: DEDA ZERO2
Seatpost: F9 CARBON
Saddle: SELLE ITALIA MODEL X

Rear Derailleur: FORCE AXS D1
Front Derailleur: FORCE AXS D1
Shift Lever: FORCE AXS D1
Cranks: FORCE D1 35/48
Cassette: XG-1270 D1 10/33
Brakes: FORCE D1
Brake Rotor: CLX R 140mm
Wheel: DT SWISS P-1800 DB 32
Cockpit: DEDA VINCI
Handlebar: DEDA ZERO2
Seatpost: F9 CARBON
Saddle: SELLE ITALIA MODEL X

Rear Derailleur: SHIMANO ULTEGRA Di2 R8150
Front Derailleur: SHIMANO ULTEGRA Di2 R8150
Shift Lever: SHIMANO ULTEGRA Di2 R8170
Cranks: SHIMANO ULTEGRA R8100 34x 50
Cassette: SHIMANO R8100 12v 11x 30
Brakes: SHIMANO ULTEGRA R8170
Brake Rotor: SHIMANO RT800 140 mm
Wheel: DT SWISS P-1800 DB 32
Cockpit: DEDA VINCI
Handlebar: DEDA ZERO2
Seatpost: F9 CARBON
Saddle: SELLE ITALIA MODEL X

Rear Derailleur: SHIMANO DURA-ACE Di2 R9250
Front Derailleur: SHIMANO DURA-ACE Di2 R9250
Shift Lever: SHIMANO DURA-ACE Di2 R9270
Cranks: SHIMANO DURA-ACE R9200 34x 50
Cassette: SHIMANO R9200 12v 11x 30
Brakes: SHIMANO DURA-ACE R9270
Brake Rotor: SHIMANO RT900 140 mm
Wheel: MAVIC COSMIC SL
Cockpit: DEDA VINCI
Handlebar: DEDA ZERO2
Seatpost: F9 CARBON
Saddle: SELLE ITALIA MODEL X

Choose size

B. Seat Tube Length: 450 mm.
L. Top Tube Length: 515 mm.
T. Head Tube Length: 130 mm.
P. Chainstay Length: 408 mm.
C. Wheel Base: 977 mm.
F. Bottom Bracket to front wheel center: 579 mm.
X. Head Tube Angle: 71.5°
Z. Seat Tube Angle: 75°
S. Stack: 529 mm.
R. Reach: 378 mm.

B. Seat Tube Length: 480 mm.
L. Top Tube Length: 536 mm.
T. Head Tube Length: 150 mm.
P. Chainstay Length: 408 mm.
C. Wheel Base: 980 mm.
F. Bottom Bracket to front wheel center: 581 mm.
X. Head Tube Angle: 72.5°
Z. Seat Tube Angle: 74°
S. Stack: 550 mm.
R. Reach: 378 mm.

B. Seat Tube Length: 510 mm.
L. Top Tube Length: 548 mm.
T. Head Tube Length: 170 mm.
P. Chainstay Length: 408 mm.
C. Wheel Base: 982 mm.
F. Bottom Bracket to front wheel center: 584 mm.
X. Head Tube Angle: 73°
Z. Seat Tube Angle: 73.5°
S. Stack: 571 mm.
R. Reach: 379 mm.

B. Seat Tube Length: 540 mm.
L. Top Tube Length: 565 mm.
T. Head Tube Length: 195 mm.
P. Chainstay Length: 408 mm.
C. Wheel Base: 991 mm.
F. Bottom Bracket to front wheel center: 593 mm.
X. Head Tube Angle: 73.5°
Z. Seat Tube Angle: 73.25°
S. Stack: 597 mm.
R. Reach: 385 mm.

B. Seat Tube Length: 570 mm.
L. Top Tube Length: 587 mm.
T. Head Tube Length: 220 mm.
P. Chainstay Length: 408 mm.
C. Wheel Base: 1010 mm.
F. Bottom Bracket to front wheel center: 612 mm.
X. Head Tube Angle: 73.5°
Z. Seat Tube Angle: 73°
S. Stack: 621 mm.
R. Reach: 397 mm.

Choose color

Personaliza tu F9 Only

Puedes personalizar los colores de tu F9 en nuestro personalizador.

Access the customizer

Customize add-ons

Wheels

Select a wheel

Handlebar / Cockpit

Select a handlebar / Cockpit
